    手持式車底視頻檢查儀JZ600-D9-Handheld Vehicle Chassis Video Inspector JZ600-D9

    帶拖輪車底檢查 車輛多角度檢查倆用多角度細節 JZ600-D9-A是一款多功能360度旋轉車輛檢測成像系統。真正的1080P雙高清500萬車用檢測錄像掃描儀。7寸高清彩色液晶顯示屏同時顯示掃描圖像,支持64GB SD卡存儲;支持拍照,錄

    在線訂購




       JZ600-D9是一款多功能360度旋轉車輛檢測成像系統。真正的1080P雙高清500萬車用檢測錄像掃描儀。

        7寸高清彩色液晶顯示屏同時顯示掃描圖像,支持64GB SD 卡存儲;
        支持拍照,錄像,回放。視頻同步顯示無延時。效果趕超ipone 5S.
        一鍵開啟式遮陽罩和5000mAh 大容量電池,方便攜帶戶外作業。
        LEMO雷莫高清數字接口,牢固耐用,不會脫落。
        2米輕便伸縮桿臂鏡無抖動,500萬高清攝像頭配置6個LED可以讓你查看那些狹窄及黑暗處的真實狀況以視頻的形式呈現在你眼前,分析處理問題得心應手。
        500萬像素抗震底盤高清攝像頭配備16個高亮LED看得更遠更清楚。
        耐磨工業級萬向底盤輪子,適用于各種路況的車底檢測。
        高檔抗壓耐用的鋁合金外箱方便攜帶。

        The JZ600-D9is a versatile 360 degree rotating vehicle inspection imaging system. A true 1080P dual HD 5 million vehicle inspection video scanner.

        7" HD colour LCD display showing scanned images simultaneously and supporting 64GB SD card storage;

        Supports photo, video and playback. Simultaneous video display without delay. The effect exceeds that of the ipone 5S.

        One-touch opening sunshade and 5000mAh battery for easy portability for outdoor work.

        LEMO HD digital interface, solid and durable, will not fall off.

        The 2m lightweight telescopic pole arm mirror is shake-free and the 5 megapixel HD camera with 6 LEDs allows you to view the real conditions in those narrow and dark places in the form of a video, so you can analyse and deal          with problems with ease.

        The 5 megapixel shock-resistant chassis HD camera is equipped with 16 bright LEDs to see further and more clearly.

        Wear-resistant industrial grade universal chassis wheels for underbody inspection in all road conditions.

        High grade pressure resistant and durable aluminium alloy outer case for easy portability.




         規格參數 Specification parameters:


    底盤攝像頭

    攝像器件

    1/2.5  CMOS 索尼

    像素

    500萬:3200(H)×1800(V)

    圖像傳感器尺寸

    5.6mm(H)×3.14mm(V)

    LED

    16 個高亮LED燈

    最低照度

    0.08Lux/F1.2

    鏡頭

    3.6mm F1.2  (H )90 °視角

    HDMI

    FPD-LinkⅢ

    輪子

    萬向耐磨輪子

    尺寸&重量

    37 x 46mm, 35g(僅攝像頭)

    線(5芯高速線)

    線徑:3.5mm   長度:2.7

    軟管攝像頭

    攝像器件

    1/3 CMOS Sensor

    像素

    500萬:3200(H)×1800(V)

    圖像傳感器尺寸

    5.07mm(H)×3.38mm(V)

    最低照度

    0.2Lux/F1.2

    LED

    6個高亮LED燈

    鏡頭

    0.5mm F1.2 90 °視角

    HDMI

    FPD-LinkⅢ

    尺寸&重量

    18 x 28mm, 10g

    線(5芯高速線)

    線徑:3.5mm   長度:3米

    軟管

    162.5px長的軟管(總長1250px)

    伸縮桿

    收縮后長度:950px

    展開長度:4750px

    7“高清顯示器

    高清視頻輸出

    HDMI:1920* 1080;1280*720

    視頻像素(16:9)

    HDMI:1920* 1080;1280*720

    壓縮方式

    H.264

    視頻存儲

    AVI

    HDMI

    FPD-Link

    音頻范圍

    20HZ-20KHz  AAC

    音頻壓縮方式

    AAC

    圖片格式

    圖片像素500萬 :3200(H)×1800(V)

    存儲卡

    TF card  1GB-64GB

    64GB卡錄制時長

    10-32 小時

    操作系統

    Windows & Mac OS

    接口

    USB 2.0/AV-OUT

    語言

    多種

    電壓

    DC :7-24V  USB DC:5V

    電流(監控)

    600毫安

    電流(錄像)

    700毫安

    充電器

    DC 12V  2A

    電源

    5000毫安時鋰電池

    錄制時間

    ≥10小時

    尺寸

    177mm x120mm x 20mm

    重量

    350g


    Chassis

    camera

    Camera devices

    1/2.5 CMOS Sony

    Pixel

    5 megapixels:3200(H)×1800(V)

    Image sensor size

    5.6mm(H)×3.14mm(V)

    LED  Light

    16 high intensity LEDs

    Minimum Illumination

    0.08Lux/F1.2

    Footage

    3.6mm F1.2  (H )90 °Perspectives

    HDMI

    FPD-LinkⅢ

    Wheels

    Universal wear-resistant wheels

    Size & Weight

    37 x 46mm, 35g(Camera only)

    Wire (5 core high speed cable)

    Wire diameter:3.5mm   Length:2.7 m

    Hose camera

    Camera devices

    1/3 CMOS Sensor

    Pixel

    5 megapixels:3200(H)×1800(V

    Image sensor size

    5.07mm(H)×3.38mm(V)

    Minimum Illumination

    0.2Lux/F1.2

    LED Light

    6 high intensity LEDs

    Lens

    0.5mm F1.2 90 °view

    HDMI

    FPD-LinkⅢ

    Size & Weight

    18 x 28mm, 10g

    Wire (5 core high speed cable)

    Wire diameter3.5mm   Length:3m

    Hose

    162.5px long hose (1250px total length)

    Telescopic

    Rods

    Length after shrinkage:950px

    Expanded length:4750px

    7" HD

    monitor

    HD video output

    HDMI:1920* 1080;1280*720

    Video pixels(16:9)

    HDMI:1920* 1080;1280*720

    Compression method

    H.264

    Video Storage

    AVI

    HDMI

    FPD-Link

    Audio Range

    20HZ-20KHz  AAC

    Audio compression methods

    AAC

    Image format

    Image pixels500萬 :3200(H)×1800(V)

    Memory Cards

    TF card  1GB-64GB

    64GB card recording time

    10-32 Hours

    Operating systems

    Windows & Mac OS

    Interface

    USB 2.0/AV-OUT

    Language

    Multilingual

    Voltage

    DC :7-24V  USB DC:5V

    Current (monitoring)

    600 mA

    Current (video)

    700 mA

    Charger

    DC 12V  2A

    Power supply

    5000 mAh lithium battery

    Recording time

    ≥10小時

    Dimensions

    177mm x120mm x 20mm

    Weight

    350g




    包裝:

    1*1080P  500W高清軟管攝像頭
    1*500W
    高清底盤攝像頭
    1*7
    寸高清顯示器
    1*2
    米伸縮桿
    1*
    高清數據線
    1*充電器

    1*鋁合金外箱

    包裝后重量: 8KG

    尺寸:盒子的凈尺寸長64CM,寬32CM,高14CM,包裝好后,長66*寬35*高17,體積重7.97KG,包裝好了之后的實際重量是7.5KG左右。

    Packaging:

    1*1080P 500W HD Hose Camera

    1*500W HD Chassis Camera

    1*7 inch HD monitor

    1*2m telescopic pole

    1*HD data cable

    1*Charger

    1*Aluminium alloy outer case

    Weight after packing: 8KG

    Size: the net size of the box is 64cm long, 32cm wide and 14cm high, after packing, the length is 66*35*17 high, the volume weighs 7.97KG, the actual weight after packing is about 7.5KG.
